D600 (LENS)
I.C.T
| Quantity: | |
|---|---|
• High cost performance;
• Non-contact jet valve to realize smaller dispensing diameter and wider application area
• Jet valve can improve the reliability and uniformity of dispensing, and improve the output and material utilization rate;
• Minimum width of excessive glue can be controlled in 0.2mm(related to the configuration and glue);
• Chip edge identification is much more accurate than mark-point identification.
• ID identification, automatic program calling, fool-proofing and data statistics function helps to realize smart manufacturing.
Platform System
Integral frame, marble platform supporting moving parts, moving parts using imported accessories, to ensure high accuracy and stability of equipment operation.
Dispensing System
Needle dispensing and spray valve dispensing can be selected. Spray valve dispensing can be fixed and rotary. CCD camera, laser altimeter and glue sensor can be selected.
Calibration System
Calibration Platform Standards: 0.1mg Electronic Scale, Scale, Ceramic Plate, Mechanical Height Detection, Vacuum Cleaning, Gluing Cup
| Model | I.C.T-D450 | I.C.T-D600(LENS) | I.C.T-D1200(LENS) |
| Dispensing Range | X400*Y400*Z50mm | X600*Y400*Z50mm | X1200*Y400*Z50mm |
| Product Weight | Max.4.5kg | ||
| Product Thickness | Max.6mm | ||
| Maximum Speed | 2000mm/s | ||
| Vision Methodology | CCD | ||
| Cleaning System | Auto | ||
| Injection Valve Speed | 200 points/s | ||
| Dispensing Accuracy | ±0.02mm | ||
| Repeated Accuracy | ±0.01mm | ||
| Weight | 650 Kg | 750 Kg | 950 Kg |
| Dimension | W770*D1200*H1500mm | W880*D1200*H1500mm | W1590*D1200*H1500mm |
