I.C.T TC-A | SMT Telescopic Conveyor

PCB SMT Telescopic Conveyor
Buy it with your trusted partner! I.C.T brings 26 years of experience in the SMT industry.
Highlights: On-site installation and training Available, 24/7 Customer Service. Highly Trained Experts.Accurate and economical. Vision guided DIY kit. Easy To Assemble. Open Source Software.
  • TC-A

  • I.C.T

Availability:
Quantity:

High Quality Automatic PCB SMT Telescopic Conveyor for Dual-lane SMD Line


Introduction

High quality SMT conveyor, PCB link conveyor, automatic inspection conveyor, dual-lane SMT link/inspection conveyor, cooling conveyor, telescopic conveyor, used for SMT SMD Production Line


Telescopic Conveyor TC-A

1.Strong,firm and stable design.

2.Telescopic mechanism closed design high safety

3. Aluminum structure, Bottom weight design, not easy to shift..

4. increased load without interference.

5.Smooth and precise translation (stepper motor).

6.Minimize clearance between conveyor.

7.Compatible SMEMA interface.



SMT Telescopic Conveyor

Modular design, optional assembly as per client's requipment.

Rugged steel design, improves equipment stability.

Smooth stainless steel screw to adjust the width of the rail.

Variable speed control.


Key Features:

  • Strong, Stable Design: Built with a robust frame for high stability, ensuring reliable operation even during high-speed movements.

  • Telescopic Mechanism: The closed design of the telescopic mechanism guarantees safety during operation.

  • Aluminum Structure: Lightweight but sturdy aluminum structure and a bottom-weighted design prevent shifting and provide better stability.

  • Increased Load Capacity: Capable of handling larger loads without interference, making it a perfect choice for various production scales.

  • Precise Translation: The stepper motor ensures smooth and accurate PCB movement for precise handling.

  • Minimal Clearance: Designed to minimize the clearance between conveyor parts, ensuring efficient and uninterrupted movement.

  • SMEMA Compatibility: Fully compatible with SMEMA, ensuring easy integration with other SMT equipment.


Materials Used:

  • Frame Material: Aluminum structure for lightweight and durable support.

  • Motor: Stepper motor for smooth and precise translation of PCBs.


Model TC-M(Manual)
TC-L(Manual) TC-A(Auto)
TC-B(Auto)
Dimension(mm)
1000*730*1050 1000*860*1050 1500*850*1300 1500*960*1300
PCB Size(mm)
50*50-445*330
50*50-530*460 50*50-445*350 50*50-530*460
Power Max. 120VA
Transport Height
900±20mm(or Customer Specified)
PCB Direction
L to R or R to L
Communication
SMEMA for Both In & Out
Power Supply
1 PH AC 220V 50/60Hz (Option:110V to 380V)
Weight
180 Kg
200 Kg 200 Kg 230 Kg


Options Available:

  • Automatic Width Adjustment: Allows for easy width adjustments to accommodate various PCB sizes, enhancing operational flexibility.

Frequently Asked Questions (FAQ)

  1. What is the transport height of the SMT Telescopic Conveyor?

    • The transport height of the conveyor is 900±20mm, but it can be customized based on your specific needs.

  2. What is the difference between the manual and automatic models of the SMT Telescopic Conveyor?

    • The manual models (TC-M and TC-L) require manual adjustments for width and operation, while the automatic models (TC-A and TC-B) feature automatic adjustments for width and PCB handling, providing more convenience for high-volume production.

  3. How does the telescopic mechanism work?

    • The telescopic mechanism allows the conveyor to extend and retract smoothly, adjusting to different production needs and PCB sizes, ensuring better flexibility and space optimization in the production line.

  4. Can the SMT Telescopic Conveyor integrate with other SMT equipment?

    • Yes, the conveyor is fully compatible with SMEMA for both input and output, enabling seamless integration with other SMT equipment in your production line.

  5. What PCB sizes can the SMT Telescopic Conveyor handle?

    • The conveyor can accommodate PCB sizes ranging from 5050 mm to 445350 mm (for manual models) and 5050 mm to 530460 mm (for automatic models), making it suitable for various PCB types and sizes.
