I.C.T | Hot Air Reflow Soldering Machine

Hot Air Reflow Soldering Machine
I.C.T Lyra Series Reflow Oven is made with Nitrogen Standard. Customer can add nitrogen at any time in future
I.C.T brings 26 years of experience in the SMT industry.
On-site installation and training Available. 24/7 Customer Service.
Highly Trained Experts. Accurate and economical. Vision guided DIY kit. Easy To Assemble. Open Source Software
  • I.C.T-Lyra622/622N

  • I.C.T

Availability:
Quantity:

I.C.T | Hot Air Reflow Soldering Machine


Introduction


I.C.T Lyra series lead-free reflow oven I.C.T’s mature product after years of market testing. Lyra Series Reflow oven has maintained a larger share of the market for many years. Its unparalleled heating performance and temperature control system meets the requirements of various soldering processes, It is I.C.T’s crystallization of years technical research and development.

Lyra Series Lead-free reflow is high-end reflow products committed to keeping up with market demand to enhance customers competitiveness.Its new design concept fully meets the needs of increasingly diverse processes, And considering the future direction of the industry, entirely suitable for communications, automotive electronics, home appliances, computers and other consumer electronic products.


Hot Air Reflow Soldering Machine


Reflow Soldering Oven

SMT Reflow Soldering Oven

Reflow Oven Introduce

Reflow Oven Introduce

SMT Reflow Oven Introduce

SMT Reflow Oven Introduce


Lyra Series Hot Air Reflow Soldering Machine


  • High effective flux management system

  • High stability nitrogen protection system

  • High performance cooling system

  • Support the CBS, Split Unit

Model Lyra 622/622N
Lyra 733/733N
Lyra 933/ 933N
Quantity of preheating zones
6 7 9
Quantity of peak zones
2 3 3
Max. soldering temperature
pre-heating zones 300 °C and peak zones350 °C
Quantity of cooling zones
2 2 3
Mesh Width
Standard 440mm( Option 560 & 680mm )
Rail Width
Single Rail: 50 - 460mm, Option: 50 - 686mm other Width on request. Dual Rail Standard: 50 - 290mm*2
Dimensions
5150*1400*1500mm
6250*1400*1500mm
6950*1400*1500mm
Weight
2400 / 2600 kg
2800 / 3000 kg
3200 /3400 kg

* I.C.T keeps working on quality and performance, specifications and appearance may be updated without particular notice.



FAQ 1: What is a Hot Air Reflow Soldering Machine?

Question: What is a hot air reflow soldering machine?

Answer: A hot air reflow soldering machine is a crucial piece of equipment used in Surface Mount Technology (SMT) manufacturing. It utilizes hot air to melt and reflow solder paste, ensuring secure and reliable connections between electronic components and the printed circuit board (PCB). This process is essential for producing high-quality, durable electronics, making the hot air reflow soldering machine a vital tool in modern electronics manufacturing.

FAQ 2: How Does a Hot Air Reflow Soldering Machine Work?

Question: How does a hot air reflow soldering machine work?

Answer: A hot air reflow soldering machine works by passing PCBs through a series of temperature-controlled zones. The process typically includes preheating, soaking, reflow, and cooling stages. In the reflow stage, hot air is used to heat the solder paste to its melting point, causing it to reflow and create strong, electrically conductive bonds between the components and the PCB. This precise temperature control ensures consistent and high-quality solder joints, which are critical for the performance and reliability of electronic devices.

FAQ 3: What Are the Benefits of Using a Hot Air Reflow Soldering Machine in SMT Manufacturing?

Question: What are the benefits of using a hot air reflow soldering machine in SMT manufacturing?

Answer: Using a hot air reflow soldering machine in SMT manufacturing offers several key benefits:

  1. High Precision: It provides precise temperature control, ensuring consistent and reliable solder joints.

  2. Efficiency: The automated process increases production efficiency, reducing the time and labor required for soldering.

  3. Quality: It produces high-quality solder joints, reducing the risk of defects and improving the overall reliability of electronic products.

  4. Versatility: Suitable for a wide range of PCB designs and component types, making it an essential tool for various electronic manufacturing applications.
