High Speed On-line PCBA AOI Machine Inspection Systems
On Line AOI V5000H Introduction:
For SMT pre-reflow, post-reflow inline inspection Granite platform, greatly improve machine precision and stability Programmable RGB+W LED lighting source Telecentric lens with constant magnification and low distortion response to high compone.
1. LOG automatic collecting and storage function,NG warning/alarm function, Remote programming&debugging.
2. Inspection ability:insufficient,short,slodering hole,solder covering pin,contamination,misalignment,missing part,skewed,billboard,mounting on side,overturn,wrong part,damaged,float,polarity,pseudo soldering,empty solder,excessive glue etc.
3. Perfect SPC collects NG information off line and generates all kinds of production tables automatically.
4. Mature control center function,clear software interface.
5. Good stability(GR&R<10% @6 Sigma,CPK>1.33(Test deviation accuracy less than ±0.25mm.
6. Camera move,conveyor fixed during test. 7.PCB warpage conpensation:total Mark compensation calibration,conponent position frame compensation.
Granite Platform and Frame
Industrial camera+Telecentric lens
Entire FOV Assist Position
Model | I.C.T-V5000H |
FOV | 15u(36*30mm)/10u(24*20mm) |
Camera | 5M pixel intelligent digital industrial camera |
Lens | Telecentric lens |
Light | 4 color ring LED light,RGB+W |
Inspection Item | Component test,soldering test |
Mini Component | 01005chip,0.3pitch IC and Special shaped |
Operation System | Windows 7 |
PCB Size | 50*50~510*600mm |
PCB Thickness | 0.3 ~ 6.0mm |
PCB Warpage | ±3.0mm |
PCB Weight | Max:3Kg |
PCB Height | Top:25mm,Bottom:45mm adjustable |
X/Y Driver | AC servo driver,repeat accuracy 0.01mm |
Platform | Granite |
Power | AC220 50/60Hz,5A |
Compressed Air | 0.4 ~ 0.6Mpa |
Weight | 750Kg |
Dimension | 940*1360*1500mm(excluding the light) |
