I.C.T Automatic SMT Dual-rails PCB Unloader

Share to:

I.C.T Automatic SMT Dual-rails PCB Unloader

Name: I.C.T Automatic SMT Dual-rails PCB Unloader
Brand: Dual-rails SMT Unloader
Rating: 5.0 (43 reviews)

Dual-rails SMT Unloader
Buy it with your trusted partner! I.C.T brings 26 years of experience in the SMT industry.
Highlights: On-site installation and training Available, 24/7 Customer Service. Highly Trained Experts.Accurate and economical. Vision guided DIY kit. Easy To Assemble. Open Source Software.

Brand:
Dual-rails SMT Unloader

Availability:

Quantity:



Inquire Add to Basket

I.C.T Automatic SMT Dual-rails PCB Unloader

Introduction

The Dual-rails SMT Unloader is a high-performance solution designed for efficient PCB unloading in SMT production lines. With a strong and stable design, advanced pneumatic clamping, and automatic fault diagnosis, this unloader ensures smooth and reliable operation. The PLC-controlled system and touchscreen interface provide ease of use, while the SMEMA compatibility ensures seamless integration with existing SMT equipment.

High quality PCB loader unloader, SMT magazine loader, mini cyclic Loader, mini size SMT loader, 90 degree SMT magazine loader, SMT Automatic Vacuum and Magazine Loader, NG/ OK unloader, for SMT SMD Production Line.

✔ Strong, firm, and stable design – Ensures durability and reliability.
✔ Touchscreen & PLC control – Simplifies operation and enhances precision.
✔ Pneumatic top & bottom clamps – Securely hold the magazine rack in place.
✔ Zero PCB breakage guarantee – Special gas circuit design ensures safety.
✔ Automatic fault code display – Quickly identifies and reports issues.
✔ Wear-resistant cables – Long service life, reducing maintenance costs.
✔ SMEMA interface – Compatible with SMT production lines.

Dual-rails SMT Unloader

Modular design, optional assembly as per client's requipment.

Rugged steel design, improves equipment stability.

Top & Bottom pneumatic clamps to secure magazine rack.

Soft touch LED control panel or touch screen can be selected.

Model （Unloader)	DUL-M	DUL-L	DUL-LL	DUL-XL
Dimension(mm)	180014351250	206516901250	233018101250	233019501250
PCB Size(mm)	5050-330250	5050-445330	5050-530390	5050-530460
Rack Size(mm)	355320563	460400563	535460570	535530570
Control System	PLC
Power Supply	1 PH AC 220V 50/60Hz (Option:110V to 380V)
Weight	320 Kg	350 Kg	380 Kg	410 Kg

Optional Features

✔ Automatic width adjustment – Adapts to various PCB sizes without manual intervention.
✔ Dual-size magazine – Supports multiple magazine sizes for flexible operation.

Frequently Asked Questions (FAQ)

1. What is the function of an SMT Unloader in a PCB production line?

A: An SMT unloader is used to automatically transfer and store completed PCBs into magazine racks after the SMT assembly process. It ensures smooth production flow and minimizes manual handling.

2. What is the difference between a single-rail and a dual-rail SMT unloader?

A: A single-rail SMT unloader supports one PCB lane at a time, while a dual-rail SMT unloader can handle two PCB lanes simultaneously, improving efficiency and reducing cycle time in high-volume production environments.

3. Is the Dual-rails SMT Unloader compatible with my existing SMT production line?

A:Yes, this unloader is SMEMA-compatible, ensuring seamless integration with standard SMT equipment, including pick-and-place machines, reflow ovens, and inspection systems.

4. How often does the Dual-rails SMT Unloader require maintenance?

A: The maintenance frequency depends on the usage and operating conditions. Under normal operating conditions, it's recommended to perform routine maintenance every 3 to 6 months. This includes checking the pneumatic clamps, control system, and cables. Regular maintenance ensures the machine operates at peak performance.

5. Can the Dual-rails SMT Unloader handle different types of PCB materials?

A: The Dual-rails SMT Unloader is designed to handle a variety of PCB materials. The special gas circuit design and pneumatic clamps minimize stress on the PCBs, making it suitable for fragile or delicate materials. Whether you're working with rigid, flexible, or high-density PCB materials, this machine can handle them efficiently and safely.
