I.C.T Barcode Scanning Conveyor – Intelligent PCB Tracking for Smart SMT Lines
Automated | Accurate | High-Speed
The I.C.T Barcode Scanning Conveyor is an advanced Industry 4.0 solution designed for PCB barcode scanning and tracking in SMT production lines. By high-precision barcode scanners with automated conveyor systems, this equipment ensures accurate PCB identification, enhancing traceability and process control.
Best choice for use with laser marking machines and inspection systems (AOI/SPI), it enables efficient data collection, workflow automation, and system integration.
PCB Barcode Scanning Conveyor
Modular design, optional assembly as per client's requipment.
Rugged steel design, improves equipment stability.
Top & Bottom pneumatic clamps to secure magazine rack.
Soft touch LED control panel or touch screen can be selected.
| Body Material | European standard aluminum alloy | China | |
| PLC | Panasonic | Japan | |
| Code Reader | Keyence | Japan | |
| Magnetic Switch | SMC | Japan | |
| Ball Screw | TBI | Taiwan | |
| Electromagnetic Valve | AirTAC | Taiwan | |
| Limit Switch | Omron | Japan | |
| Sensor | Pepperl+Fuchs/Panasonic/Omron | Germany/Japan | |
| Relay | APT | Germany | |
| Model | BCS-M | BCS-L | BCS-LL |
| Dimension(mm) | 1000*964*1450 | 1000*964*1450 | 1000*964*1450 |
| PCB Size(mm) | 50*50-330*250 | 50*50-445*330 | 50*50-530*390 |
| CycleTime | Approx.5 Seconds | ||
| Control System | PLC | ||
| Power | Max 250 VA | ||
| Transport Height | 900±20mm (or Customer Specified) | ||
| Transport Mode | 4mm Anti-staticbelt | ||
| PCB Direction | L to R or R to L | ||
| Communication | SMEMA for Both In & Out | ||
| Power Supply | 1 PH AC 220V 50/60Hz (Option:110V to 380V) | ||
| Weight | 340kg | 360kg | 380kg |
✔ Automatic Width Adjustment – Effortless PCB size adaptation.
✔ MES System Integration – Enables real-time data tracking and process control.
