I.C.T SC-500 | 500mm SMT Conveyor Transmission PCB Lift Conveyor

Share to:

I.C.T SC-500 | 500mm SMT Conveyor Transmission PCB Lift Conveyor

Name: I.C.T SC-500 | 500mm SMT Conveyor Transmission PCB Lift Conveyor
Brand: I.C.T
Rating: 5.0 (92 reviews)

I.C.T | 500mm SMT Conveyor Transmission PCB Lift Conveyor is usually used to transfer and cooling PCBA after reflow soldering with rugged steel design, improves equipment stability.

Model:
SC-500
Brand:
I.C.T

Availability:

Quantity:



Inquire Add to Basket

I.C.T SC-500 | 500mm SMT Conveyor Transmission PCB Lift Conveyor

Introduction

High quality adjustable speed SMT conveyor, PCB turn conveyor, translation shuttle conveyor, high-end SMT upscale inspection conveyor, high-end dual-lane SMT upscale inspection conveyor, PCB standard reject conveyor, SMT sealing conveyor, PCB barcode scanning conveyor, for SMT SMD Production Line

The Standard SMT Link/Inspection Conveyor is a modular and versatile conveyor system designed for PCB transportation and inspection in SMT assembly lines. It is equipped with rugged steel components for enhanced stability, an adjustable stainless steel screw rail for precise control, and various other features to meet specific client needs.

Key Features:

Modular Design: Customizable assembly per client’s requirements for flexibility in various setups.
Durability: Built with rugged steel materials, enhancing equipment stability.
Adjustable Rail: Smooth stainless steel screw adjusts the width of the rail, ensuring compatibility with different PCB sizes.
Variable Speed Control: Offers flexible speed adjustments to suit different operational needs.
PCB Testing Mode: Efficient system for testing circuit boards during the assembly process.
Dedicated Aluminum Slot: Prevents PCB damage and sticking, ensuring smoother operation.
Heavy Duty Design: The sturdy bottom design minimizes shifting, ensuring reliable operation.
Customization Options: Machine length can be customized to fit various factory configurations.
SMEMA Compatibility: Ensures seamless integration with other equipment in the SMT line.

SMT Conveyor

Modular design, optional assembly as per client's requipment.

Rugged steel design, improves equipment stability.

Top & Bottom pneumatic clamps to secure magazine rack.

Soft touch LED control panel or touch screen can be selected.

Body Material		Weldingofmetalmaterials			China
Sensor		Pepperl+Fuchs/Panasonic/Omron			Germany/Japan
Rail		Aluminum (mold making)			China
Belt		4mm antistatic belt			China
Guide Screw		High precision ball screw			Taiwan
Model	SC-500	SC-600	SC-1000	SC-1200	SC-1500	SC-2000
Rail Length	500 mm	600 mm	1000 mm	1200 mm	1500 mm	2000 mm
Dimension(mm)	500700950	600700950	1000700950	1200700950	1500700950	2000700950
PCB Width	50 to 350 mm
Power Supply	1 PH AC 220V 50/60Hz (Option:110V to 380V)
Weight	50 Kg	50 Kg	55 Kg	85 Kg	125 Kg	150 Kg
Option:
Touchscreen		Automaticwidthadjustment			SegmentedTransmission
Metalchain		LEDInspectionLight

Options Available:

Touchscreen: Optional interface for ease of use.
Automatic Width Adjustment: For fast and easy adjustment to PCB width.
Metal Chain: Optional metal chain for transmission.
LED Inspection Light: Optional light to assist in inspection during the assembly process.
Segmented Transmission: For more precise control of PCB movement.

Frequently Asked Questions (FAQ)

What is the maximum PCB width supported by the SMT Link/Inspection Conveyor?

The conveyor supports PCB widths ranging from 50 mm to 350 mm, providing flexibility for various PCB sizes in the production process.

Can I adjust the speed of the conveyor?

Yes, the conveyor comes with variable speed control, allowing you to adjust the speed according to your production requirements.

Is the conveyor system compatible with other SMT equipment?

Yes, the conveyor is fully SMEMA compatible, which means it can seamlessly integrate with other equipment in the SMT assembly line.

What materials are used in the construction of the conveyor?

The conveyor features high-quality materials, including metal for the body, precision ball screws for the guide system, and anti-static belts for safe handling of PCBs.
