PCB Conformal Coating Machine in SMT PCB Assembly Line

Overview

Product Description

SMT PCBA coating line solution(PCBA coating loader+ selective coating machine +coating conveyor + IR curing oven)
1,PLC control, touch screen operation, fault acousto-optic alarm and menu display.
2, Continuous surface spraying, automatic detecting initial distance and coated width.
3, Stepper motor reciprocating coating, can be arbitrary set about PCB before and after the offset. Special aluminum alloy orbit
and stainless steel conveyor chain.
4,Equipped with a fan-shaped spray glue valve, can be automatically.
5,Rubber valve automatically soak, to prevent clogging.

PCBA Coating Machine T550

1.PLC control, windows operation, fault acousto-optic alarm and menu display.

2.Continuous surface spraying, automatic detecting initial distance and coated width.

3.Servo motor reciprocating coating, can be arbitrary set about PCB before and after the offset.Special aluminum alloy orbit and stainless

steel conveyor chain.

4.Equipped with a fan-shaped spray glue valve, can be automatically.

5.Rubber valve automatically soak, to prevent clogging.

6.Inlet and outlet are equipped with communication socket, can online connection with other machines.

7.Independent paint container barrels

8.Equipped with exhaust gas collection, outfalls.

PCBA Coating Loader &Unloader

1.Strong,firm and stable design.

2.'soft touch' LED control panel or touch screen can be selected.

3.Top & bottom pneumatic clamps to secure magazine rack.

4.No PCBA breakage guaranty because of special gas circuit design.

5.Automatical diagnosing fault code display function.

6.Wear-resistant cable and have long service life.

7.Compatible SMEMA interface.

PCBA Coating Conveyor

1.Modular design, optional assembly as per client's requirement.
2.Rugged steel design, improves equipment stability .
3.Smooth stainless steel screw to adjust the width of the rail.
4.Variable speed control.
5.Circuit board testing mode.
6.Using a dedicated aluminum slot for transfer orbit to prevent PCB stuck.
7.Heavier bottom design, not easily shift.

PCBA Coating IR Oven
1. Control system:Instrument or plc+touch screen or PC control optional,make sure machine working steadily.
2. IR heating: top zones IR heating,good heater compensatory,High thermal efficiency,energy saving,speedy heating, Temperature Accuracy ± 1.5 ºC, room temperature settling time less than 20 minutes.
3. PID intelligent precision controller,automatically control heating volume, fuzzy control function changes the external heating fast,and by internal control ensures more balanced temperature.
4.Use imported big current solid relay,without touch point output,safe,reliable,with special SSR radiator,greatly improve thermal efficiency and lifetime.

UV Curing Oven
1. Control system:Instrument or PLC+touch screen control,make sure machine working steadily.
2. UV lamp lifetime can reach 1000-1200 hour,the energy of UV is higher and the penetration ability of the coating is stronger. abnormal
lamp protection device.
3. Conveyer belt mabe by Teflon materials,has no pole speed regulation, and speed is stable and adjustable.
4. Focus design, import high light reflector lamp shade, instant drying, fast speed..
5. Independent cooling area ensures the low temperature when PCB comes out.

Successful Experience:
I.C.T's customer in 35 countries around the world
1. We have been helping customers to build a lot of new factories around the world.
2. Training more than 500 experts and technician for customers.
3. Became the most reliable Chinese partner for you.

For SMT factory setup,we can do for you:
1. We provide fulL SMT solution for you
2. We provide core technology with our equipments
3. We provide the most professional tech service
4. We have wealthy experience on SMT factory setup
5. We can solve any question about SMT

I.C.T SMT Production Line

Packing Method:
Standard Wooden Case with Vacuum Package

Shipping Way:
1. By air, for sample and small package,international express like DHL, UPS, EMS...
2. By sea, for large package and quantity;
3. Other ways as customer requested.

Delivery Time:
35 Days

FAQ

Q: What is PCBA coating?

A: A conformal coating shields the parts and visible copper on a printed circuit board (PCBA) from harm. The condition of a component, especially its cleanliness, affects how well the conformal coating functions. Using masking is a helpful method to get a PCB or component ready for the conformal coating procedure.

Q：What is conformal coating made of?

A：Conformal coating is typically made of various materials, such as acrylics, silicones, or urethanes. These materials are carefully formulated to provide protective and insulating properties for electronic components on printed circuit boards (PCBs). The choice of coating material depends on the specific requirements of the application, including factors like environmental conditions, electrical insulation, and ease of application. Each type of coating material has its advantages and is designed to meet different needs in the electronics manufacturing process.
