I.C.T | PCB Handling Equipment SMT Inspection Conveyors Guangdong

Share to:

I.C.T | PCB Handling Equipment SMT Inspection Conveyors Guangdong

Name: I.C.T | PCB Handling Equipment SMT Inspection Conveyors Guangdong
Brand: I.C.T
Rating: 5.0 (86 reviews)

I.C.T | PCB Handling Equipment SMT Inspection Conveyors Guangdong
Transmission PCB Lift Conveyor is usually used to transfer and cooling PCBA after reflow soldering with rugged steel design, improves equipment stability.

Model:
SC-500
Brand:
I.C.T

Availability:

Quantity:



Inquire Add to Basket

I.C.T | PCB Handling Equipment SMT Inspection Conveyors Guangdong

Introduction

High quality adjustable speed SMT conveyor, PCB turn conveyor, translation shuttle conveyor, high-end SMT upscale inspection conveyor, high-end dual-lane SMT upscale inspection conveyor, PCB standard reject conveyor, SMT sealing conveyor, PCB barcode scanning conveyor, for SMT SMD Production Line.

1. This equipment is usually used to transfer and cooling PCBA after reflow soldering.

2. Rugged steel design, improves equipment stability.

3. Smooth stainless steel screw to adjust the width of the rail.

4. Variable speed control.

5. Circuit board testing mode.

6. Using a dedicated aluminum slot for transfer orbit to prevent PCB stuck.

7. Heavier bottom design, not easily shift.

8. Machine length can be customized.

9. Compatible with SMEMA interface.

*: Option: Dual rail

PCB Handling Equipment SMT Inspection Conveyors Guangdong

Modular design, optional assembly as per client's requipment.

Rugged steel design, improves equipment stability.

Top & Bottom pneumatic clamps to secure magazine rack.

Soft touch LED control panel or touch screen can be selected.

Body Material		European standard aluminum alloy			China
Sensor		Omron			Japan
Rail		Aluminum (mold making)			China
Belt		12mm antistatic belt			China
Guide Screw		High precision ball screw			Taiwan
Model	HC-500	HC-600	HC-1000	HC-1200	HC-1500	HC-2000
Rail Length	500 mm	600 mm	1000 mm	1200 mm	1500 mm	2000 mm
Dimension(mm)	500700950	600700950	1000700950	1200700950	1500700950	2000700950
PCB Width	50 to 350 mm
Power Supply	1 PH AC 220V 50/60Hz (Option:110V to 380V)
Weight	80 Kg	80 Kg	85 Kg	115 Kg	155 Kg	180 Kg

FAQ

1: What is PCB Handling Equipment SMT Inspection Conveyor?

Question: What is PCB Handling Equipment SMT Inspection Conveyor?

Answer: PCB Handling Equipment SMT Inspection Conveyor is a specialized piece of machinery used in the surface mount technology (SMT) assembly process to handle and inspect printed circuit boards (PCBs). These conveyors are designed to transport PCBs through various stages of inspection, ensuring that each board meets quality standards. They can be equipped with features like automated inspection cameras, adjustable conveyor speeds, and ergonomic designs to facilitate thorough and efficient inspection processes.

2: Why Choose PCB Handling Equipment SMT Inspection Conveyors from Guangdong?

Question: Why choose PCB Handling Equipment SMT Inspection Conveyors from Guangdong?

Answer: Choosing PCB Handling Equipment SMT Inspection Conveyors from Guangdong offers several advantages. Guangdong is a major hub for electronics manufacturing, known for its advanced technology, high-quality production standards, and competitive pricing. Manufacturers in this region often provide innovative designs, robust construction, and reliable performance in their SMT inspection conveyors. Additionally, they offer excellent customer support and after-sales service, ensuring smooth operation and minimal downtime in your production line.

3: What Features Should I Look for in PCB Handling Equipment SMT Inspection Conveyors?

Question: What features should I look for in PCB Handling Equipment SMT Inspection Conveyors?

Answer: When selecting PCB Handling Equipment SMT Inspection Conveyors, consider features such as adjustable conveyor speeds, high-resolution inspection cameras, and compatibility with various PCB sizes. Look for systems with user-friendly control interfaces, robust construction, and easy maintenance. Additionally, ergonomic designs that facilitate operator comfort and efficiency, as well as the ability to integrate seamlessly with existing SMT assembly lines, are crucial for optimizing your manufacturing process.
