In-Circuit Test ICT Equipment for PCB Test In Circuit Manufacturers

In-Circuit Test ICT Equipment is a key automatic testing equipment that plays a vital role in the electronic product manufacturing process and ensures product quality and reliability.
  • I.C.T-Q518D

  • I.C.T

  • In-Circuit Test ICT Equipment

Availability:
Quantity:

In-Circuit Test ICT Equipment for PCB Test In Circuit Manufacturers


Overview


ICT-Tester-Q518D

In-Circuit Test ICT Equipment for PCB Test


Make Your PCB with high quality


PCB In-circuit Testing (ICT) is an automatic testing equipment used in the manufacturing process of electronic products. It is widely used in PCB (Printed Circuit Board) production lines to detect whether the welding, connection and component installation on the circuit board comply with specifications.


Features of In-Circuit Test ICT Equipment for PCB Test:

  1. Equipped with EC jet test technology

  2. Design of CMOS + replay switch card

  3. True broadband test technology

  4. Humanized win7 interface, simple operation and easy to use

  5. Powerful board view

  6. Five wire test technology, up to four terminal components can be tested

  7. ATPD automatic test program debugging

  8. Improve statistical analysis reports and effectively monitor production quality


Specifications:


Model I.C.T-Q518D
PCB Size 500mm x 380mm(STANDARD)
Test points 256points Standard(1024points is optional)
Switch Card 128/pot
Isolated points 10/cart
The test speed

0.5sec/1024 points(Open/Short)

2ms ~ 40ms/step(component)

Test range

Resistance 0.1 Ω ~ 40M Ω The accuracy is 0.05 Ω~ 100M Ω ( 2-wire) ± 1% - 5% (four wire) 0.05 Ω.

Capacitance 1pf ~ 40MF precision ± 2%-5%.

Inductance 1uh ~ 50h, accuracy 2% - 5%.

Diodes 0.1 ~ 6V accuracy ± 1%-3%.

Stabilized voltage diode 0.1 ~ 15V precision ± 1%-3%.

Measurement of VCE saturation voltage at three terminals of transistor β value.

Three terminal test of field effect transistor VDS, CDs, RD (on).

Optical coupler and relay, with four terminals to test its conduction voltage or resistance.

Power Supply AC:100~240,50/60HZ,3Kw
Dimension(mm) 830*830*1600
Weight Approx:170kg

* The data is obtained under ambient temperature of 25℃ and humidity of 60%

* I.C.T keeps working on quality and performance,specifications and appearance may be updated without particular notice.
